As one of VSAT antenna manufacturers, BIRDSAT's new 80 cm KU band satellite TVRO antenna is on board now. This powerful and compact tvro satellite antenna features a shortened response time, with every improvement aimed at enhancing the quality of life at sea.
Quick response
The SP80 tvro antenna is designed with a 2-axis step motor stabilization system, which allows it to quickly and accurately adjust its position to lock onto satellite signals.
Uninterrupted connection
The SP80's unlimited azimuth range and 0° to 90° elevation range allow it to track satellites smoothly across the sky. Its durable design, with an IPX6 rating and wide temperature tolerance, ensures a reliable connection in various conditions.
Signal receiving strengthened
The SP80 TVRO antenna is optimized to receive signals in the Ka-band frequency range of 11.7GHz to 12.75GHz with both vertical and horizontal polarization. It can capture high-quality signals even in challenging conditions, ensuring a stable and clear viewing experience.
| Model Name | Radome Height |
| SP80 | 58 cm |
| Radome Diameter | Reflector Diameter |
| 55 cm | 45 cm |
| Weight | Operating Temp. Range |
| 13.5 kg | -20℃~70℃ |
| Storage Temp. Range | Water Ingress |
| -40°C ~ 80°C | IPX6 |
| Reception Frequency | Polarization |
| Ka-band ：11.7GHz~12.75GHz | Linear (V/H) |
| Minimum EIRP | Stabilized Type |
| 47 dBW | 2-Axis Step motor |
| Azimuth Range | Elevation Range |
| Unlimit | 0° ~ 90° |
| Roll & Pitch Response Rate | Turn Rate |
| 60° / sec | 60° / sec |
| RF Output | Dimensions (W × D × H) |
| 1 Output， 2 output | 26.3 cm × 15cm × 5 cm |
| Weight | Display |
| 1.47 kg | 2 line 16 character LCD module |
| Control Key | Power Input |
| 3 Integrated Push Buttons | 9.0~30.0V DC (Typ. 26W, max 50W) |
